Approaching perfection. Topper from GnarlyDudeLive features 8 feet of walk space after I added a pop top with panoramic fabric unzipping. I also added the side window and the canvas drop floor tail. Range loss 20%?, 25%? Still good enough for me on a tri-motor. The cubes make the CT livable, not just sleepable. Thoughts?
