Interesting roof rack concept to take advantage of the entire top of the Cybertruck.

And to tweak it up a notch I imagine one could come off the front bumper with vertical supports and extend the overhead pipe/lumber rack the full length of the footprint of the CT. Show me what ya got.
Advertisement



JustACTDude

New member
Joined
Aug 17, 2020
Messages
1
Reaction score
1
Location
Nebraska
Vehicles
Tundra
Country flag
These concepts are awesome, but I’m crazy confused. How are these going to attach to the CT? I’m obviously no engineer, but if the bed rail has the housing for the tonneau cover to slide, can it hold the weight of a rack being placed on it? Or how would a rack system work on the CT? Thx!


Crissa

Well-known member
First Name
Crissa
Joined
Jul 8, 2020
Messages
6,005
Reaction score
7,916
Location
Santa Cruz
Vehicles
2014 Zero S, 2013 Mazda 3
Country flag
These concepts are awesome, but I’m crazy confused. How are these going to attach to the CT? I’m obviously no engineer, but if the bed rail has the housing for the tonneau cover to slide, can it hold the weight of a rack being placed on it? Or how would a rack system work on the CT? Thx!
The structure that supports the entire truck is in those side walls. (Like a box girder bridge over a river; the skateboard is the deck, the sides are... the structure.) It has attachment points built in and is weldable stainless steel.

-Crissa


Newton

Well-known member
First Name
Newton
Joined
Apr 2, 2020
Messages
761
Reaction score
931
Location
East Bay Area, CA
Vehicles
p̶r̶i̶u̶s̶ c̶,̶ y̶o̶t̶a̶ p̶i̶c̶k̶u̶p, ⼕丫⻏🝗尺セ尺ㄩ⼕长
Country flag
The structure that supports the entire truck is in those side walls. (Like a box girder bridge over a river; the skateboard is the deck, the sides are... the structure.) It has attachment points built in and is weldable stainless steel.

-Crissa
Yea they have shown little attachment points on the prototype. they look quite small to me and only 4, one in each corner.
hopefully the real truck has better points to attach to. it would be a shame to have to weld brackets on it. although I guess another option is drilling holes and welding inset nuts, covering with a rubber plug when not in use, or a bolt with an oring on it


Last edited:

Crissa

Well-known member
First Name
Crissa
Joined
Jul 8, 2020
Messages
6,005
Reaction score
7,916
Location
Santa Cruz
Vehicles
2014 Zero S, 2013 Mazda 3
Country flag
I guess another option is drilling holes and welding inset nuts, covering with a rubber plug when not in use, or a bolt with an oring on it
My Mazda just has nuts exposed in the gutter.

I kinda wish I had some caps for them, but I've gone eight years without.

-Crissa


Dids

Well-known member
First Name
Les
Joined
Dec 21, 2019
Messages
1,147
Reaction score
2,260
Location
Massachusetts
Vehicles
04 Tacoma, 21 Cybertruck
Occupation
Self
Country flag
Yea they have shown little attachment points on the prototype. they look quite small to me and only 4, one in each corner.
hopefully the real truck has better points to attach to. it would be a shame to have to weld brackets on it. although I guess another option is drilling holes and welding inset nuts, covering with a rubber plug when not in use, or a bolt with an oring on it

I think you missed 2 points at the peak for a total of six as shown in the Tesla reveal photo of the CT with a ladder rack.
Although the last photo the lines could just be hinges for the sail storage lid

Cybertruck Ladder Rack Charging Tools 4.jpg



Last edited:

Sirfun

Well-known member
First Name
Joe
Joined
Dec 28, 2019
Messages
987
Reaction score
1,733
Location
Oxnard, California
Vehicles
Toyota Avalon, Chrysler Pacifica PHEV, Ford E-250
Occupation
Retired Sheet Metal Worker
Country flag
I think you missed 2 points at the peak for a total of six as shown in the Tesla reveal photo of the CT with a ladder rack.
Although the last photo the lines could just be hinges for the sail storage lid


When I was playing around with drawing up a rack, I saw those attachment points and it makes sense. The front is at the A-pillar, the middle is at the vertical structure behind the rear door and the back one is at the corner where all the strength is for the tailgate connection.


ldjessee

Well-known member
First Name
Lloyd
Joined
Apr 22, 2020
Messages
751
Reaction score
744
Location
Indiana, USA
Vehicles
reservation for 2 motor Cybertruck, Nissan Leaf, Subau Outback, Kawasaki Vulcan 1700 Vaquero ABS
Occupation
programmer
Country flag
They remind me of the points for the other Tesla models that have a roof rack option.


davidngo44

Well-known member
First Name
david
Joined
May 27, 2020
Messages
47
Reaction score
58
Location
91732
Vehicles
cycberstruck
Occupation
1
Country flag
When I was playing around with drawing up a rack, I saw those attachment points and it makes sense. The front is at the A-pillar, the middle is at the vertical structure behind the rear door and the back one is at the corner where all the strength is for the tailgate connection.
You are correct....hmm I did miss it. Thank you.


ShadowRoad

New member
First Name
Lane
Joined
Sep 12, 2020
Messages
1
Reaction score
1
Location
Stamford, CT
Vehicles
Subaru Impreza, Mazda RX-8 (hopefully Tesla Cybertruck in near future)
Occupation
Graphics Engineer
Country flag
What is that green thing on top? Is that what I think it is, a portable container that stores excess battery power? Cleaver......

I like the roof bed to transport full sticks of lumber but not the dually wheels
The green containers would be jerry cans of water, based on their color.


FullyGrounded

Well-known member
Joined
Nov 18, 2020
Messages
324
Reaction score
327
Location
blah
Vehicles
blah
Country flag
I really like the concept, but with a few caveats. I think the fog lights need to go, as they are redundant in a less capable way than Tesla's lightbar right there. Also, I would like to see the drag coefficient respected at least somewhat, in any design.

I would like to see a front bumper that fits like a glove to the CT, though it can protrude forward, in a clean way. I would like that bumper to house a capable winch, covered with a plate door that locks closed.

The rack would be great if it didn't extend beyond the roofline, horizontal from the peak. I would also like to see a heavy cover that could be used to streamline the whole unit when not in use. And, for my own use, I would like a rack system that falls short of the roofline by 8", enough for a closed rooftop tent to fit under the roofline. I prefer to sleep up top, and house all my comforts below in the vault and in the space between the vault and rack. It might also be nice to allow this rack to hinge, making available the solar vault to the sun exposure.

I'm thinking the cd of 0.30 is in huge part what gives the range we see in the different categories. And, I think we can carry the same gear, using a rack and bumper system that respects this. My choice of where to lose some of this is in the tires/wheels I will choose, since this can directly be attributed to significantly greater capability in very many off-road conditions that I will face. peace


Spaceologist

New member
First Name
Jeff
Joined
Dec 4, 2020
Messages
1
Reaction score
3
Location
Missouri
Vehicles
Model X, F-150, Miata
Occupation
Brewery owner
Country flag
This post just brought me to the forum via a google search. Thanks for taking the time to model it out. I can’t wait to see what the aftermarket does with the CT. SEMA is going to be awesome.


craz

Well-known member
First Name
Chris
Joined
Apr 13, 2020
Messages
56
Reaction score
87
Location
Western US
Vehicles
Dual Motor Cybertruck
Occupation
Engineer
Country flag
Sort of unrelated to the roof rack (which I love): what size tires and what ground clearance are modeled in those renders? The stance of your CT looks better than the real one imo
